PATHFINER SERIES MODELS
Supplying NDT Equipment Solutions Since 1989
Modular Video Borescope Tools and pushrod camera systems for remote visual inspection.
Our comprehensive range of Dellon videoscopes, borescopes, and industrial endoscopes gives greater versatility to visually inspect any inaccessible space easily and clearly, capturing high-definition images in real time.
Video inspection cameras have become a necessary tool for visual inspections, maintenance, and non-destructive testing (NDT) across various applications in various industries.
​
Video borescopes are essential for automotive mechanics, plumbers, aviation engineers, building inspectors, mine inspectors, and renewable energy inspectors. Our versatile visual inspection camera range allows for easy, non-destructive testing (NDT) and examinations of even the hardest-to-reach regions of interest.
​
Introducing an inspection camera into your current protocols will increase cost savings over time by allowing you to see parts of any pipe, tube, or air receiver, or look inside machinery without having to dismantle or excavate.
Need to see into regions of interest? You’re guaranteed to find a suitable product for every budget and every application within our largest range of industrial inspection camera systems.
The Dellon G+ Video Borescope Tool
The Dellon G+ Video Borescope Tool
​
-
CMOS Camera offers 1000 Thousand Pixel Resolution
-
The G+ Supports interchangeable accessory probes for quick change out lengths and diameters in the following specs
-
(2.8 mm 160 Thousand Pixel Resolution with a field of view of 120dg, Focal length 5mm to 30mm 1.5Mtr long stainless steel braided insertion tube)
-
(4.5 mm 720 Thousand Pixel Resolution with a field of view of 80dg, 10mm to 100mm 2Mtr Tungsten tip driven borescope insertion tube)
-
(6.2 & 6.4 mm 720 Thousand Pixel Resolution with a field of view of 120dg, 12mm to Infinity 2Mtr Tungsten tip driven borescope insertion tube)
-
High Contrast 5" LCD Display Monitor Providing Smooth, clear, stable, live, and static inspection images, now with HDMI Interface.
-
Mechanical Joystick Control 360 ° articulation, easy and flexible operation.
-
Rotary fine-tuning step damper makes it easy and accurate to stop at the best viewing position.
-
White balance, AGC, exposure, image mode, monitor brightness, monitor contrast, and monitor proportion are adjustable.
-
Front-end LED optimized light, adjustable illumination 5 levels, rear-end bright LED auxiliary illumination.
-
WIFI, input microphone, temperature sensor, photo stabilization, real-time image rotation, file rename, and text note functions.
-
3.7v/6000MaH Lion Battery offering 4 Hours of operation with a 5 Hour Charge Time
-
The G+ can be powered and charged at the same time from its AC Adapter.
-
Builders Inspection Camera, Engineers Inspection Camera, Wall Cavity Inspection Camera,
Boat Cavity #Borescope Inspections, Building Cavity #Borescope Inspections, Pipe Insides #Borescope Inspections, Tube #Borescope Observations, Termite #Borescope Inspections, Home Cavity #Borescope Inspections, #Borescope Industry Leaders, 1080p #Borescopes, #Borescope Intelligence Australia, #Borescope Services. Air Receiver #Borescopes, Hydraulic Cylinder #Borescope, EV #Borescope Inspections, Gearbox #Borescope, Naturally Aspirated Engine #Borescope
The Dellon GPro Video Borescope Tool
The Dellon G-Pro Video Borescope Tool
-
CMOS Camera offers 900 Thousand Pixel Resolution
-
The G-Pro Supports interchangeable accessory probes for quick change out tip-driven borescope lengths and diameters in the following specs
-
(2.4 mm 160 Thousand Pixel Resolution with a field of view of 120dg, Focal length 5mm to 30mm 1.5Mtr long stainless steel braided insertion tube)
-
(2.8 mm 300 Thousand Pixel Resolution with a field of view of 120dg, Focal length 5mm to 30mm 1.5Mtr long stainless steel or tungsten braided tip driven borescope insertion tube)
-
(3.9 mm 900 Thousand Pixel Resolution with a field of view of 120dg, 8mm to 80mm 2Mtr or 3.5Mtr Tungsten insertion tube)
-
(6.2 & 6.4 mm 900 Thousand Pixel Resolution with a field of view of 120dg, 5mm to 50mm or 12mm to Infinity 2Mtr & 3.5Mtr Tungsten insertion tube)
-
(8.4 mm 900 Thousand Pixel Resolution with a field of view of 120dg, 5mm to 50mm or 15mm to Infinity 2Mtr, 3.5Mtr or 6Mtr Tungsten insertion tube)
-
High Contrast 5" LCD Display Monitor Providing Smooth, clear, stable, live, and static inspection images.
-
Mechanical Joystick Control 360 ° articulation, tip-driven borescope with easy and flexible operation.
-
Rotary fine-tuning step damper makes it easy and accurate to stop at the best viewing position.
-
White balance, AGC, exposure, image mode, monitor brightness, monitor contrast, and monitor proportion are adjustable.
-
Front-end LED optimized light, adjustable illumination 5 levels, rear-end high-brightness LED auxiliary illumination.
-
WIFI, input microphone, temperature sensor, photo stabilization, real-time image rotation, file rename, and text note functions.
-
3.7v/6000MaH Lion Battery offering 4 Hours of operation with a 5 Hour Charge Time
-
The GoPro can be powered and charged at the same time from its AC Adapter.
-
Builders Inspection Camera, Engineers Inspection Camera, Wall Cavity Inspection Camera,
Boat Cavity #Borescope Inspections, Building Cavity #Borescope Inspections, Pipe Insides #Borescope Inspections, Tube #Borescope Observations, Termite #Borescope Inspections, Home Cavity #Borescope Inspections, #Borescope Industry Leaders, 1080p #Borescopes, #Borescope Intelligence Australia, #Borescope Services. Air Receiver #Borescopes, Hydraulic Cylinder #Borescope, EV #Borescope Inspections, Gearbox #Borescope, Naturally Aspirated Engine #Borescope
The Dellon DX Series Borescope System
The "NEW GENERATION" Dellon DX Series Borescope Systems is a major upgrade to the previous model by providing a high-resolution CMOS 720p image sensor resulting in super sharp and bright, high–quality images by adapting its objective lens tips that can be supplied, either fixed and or interchangeable, enabling change out of varying focal length camera tips.
​
✶ A huge user-friendly 7" touchscreen navigation display makes your inspections a lot nicer and more intuitive to manage.
✶ Features include a 4-way finger steerable tip articulation controller which is easily dismountable, and swappable to provide convenience for all types of inspections.
✶ The Display Controller is supplied with a 12.6 V-1A AC/DC adapter for powering and charging the system's lithium-ion battery which has a 5-hour working time and an 8-hour charging time with an onboard LED battery strength indicator.
✶The CMOS 1/4 sensor offers 720,000 pixels of excellent clarity and resolution, providing brighter images in less ideal lighting situations resulting in more clear and easier-to-read data.
✶The brightly lit 1280 x 720 7" touchscreen LCD display brightness now provides easier inspection identification in direct sunlight situations.
✶The DX ergonomic design offers a friendly interface, that is designed and suitable for a wide variety of work environments along with being compact, lightweight, and portable.
Features
​
-
8.2mm Camera Head Diameter in standard lengths of 8Mtr, 10Mtr, 15Mtr
-
7" inch high-resolution display
-
CMOS 1/4 Camera Chip with a standard depth of field being 25mm-infinity
-
Bright LED illumination 40000Lux~60000Lux
-
Detection line range up to 15m
-
360 degree viewing & four way articulation
-
SD card for photo (JPEG) and video (AVI) storage
-
Portable host suitable for single person operation
-
Continuous working time 4-5 hours rechargeable battery
Boat Cavity #Borescope Inspections, Building Cavity #Borescope Inspections, Pipe Insides #Borescope Inspections, Tube #Borescope Observations, Termite #Borescope Inspections, Home Cavity #Borescope Inspections, #Borescope Industry Leaders, 1080p #Borescopes, #Borescope Intelligence Australia, #Borescope Services. Air Receiver #Borescopes, Hydraulic Cylinder #Borescope, EV #Borescope Inspections, Gearbox #Borescope, Naturally Aspirated Engine #Borescope
The Dellon GX Series HD Borescope System
The "NEW GENERATION" Dellon GX HD Series Portable Borescope Systems is the newest generation to previous models, offering an 8-function 5" touch screen display, 6mm diameter 1080p high-definition CMOS 1/4 camera chip, and a range of 720p CMOS 1/9 camera chips all providing an extremely sharp and bright true color, high–quality video and still image captured images.
​
✶ A 5" touchscreen navigation display makes your inspections a lot nicer and more intuitive to manage.
✶ Features include a 4-way finger steerable tip articulation controller which is easily dismountable, and swappable to provide convenience for all types of inspections.
Features
-
2.8mm Camera Head Diameter in standard lengths of 2 to 3.5 Mtr
-
3.9mm Camera Head Diameter in standard lengths of 2 to 3.5 Mtr
-
6.4mm Camera Head Diameter in standard lengths of 2 to 3.5 Mtr
-
8.2mm Camera Head Diameter in standard lengths of 7.5 Mtr
-
5" inch high-resolution display
-
CMOS 1/4 Camera Chip with a standard depth of field being 25mm-infinity
-
Bright LED illumination 40000Lux~60000Lux
-
Detection line range up to 15m
-
360-degree viewing & four-way articulation (in choice of mechanical or motor-controlled steering)
-
SD card for the photo (JPEG) and video (AVI) storage
-
Portable host suitable for single-person operation
-
Continuous working time 4-5 hours rechargeable battery
Boat Cavity #Borescope Inspections, Building Cavity #Borescope Inspections, Pipe Insides #Borescope Inspections, Tube #Borescope Observations, Termite #Borescope Inspections, Home Cavity #Borescope Inspections, #Borescope Industry Leaders, 1080p #Borescopes, #Borescope Intelligence Australia, #Borescope Services. Air Receiver #Borescopes, Hydraulic Cylinder #Borescope, EV #Borescope Inspections, Gearbox #Borescope, Naturally Aspirated Engine #Borescope
The Dellon SE40 7" Touch Screen
The Dellon SE40 Engineers Push Rod Inspection System
​​
The SE-40 Engineers Camera Inspection System is a compact and portable deploy anywhere pushrod camera system with three interchangeable camera heads, these include a 40mm pan/tilt color camera a 24mm forward view color camera, and a 3Mtr x 8mm diameter 2-way tip controlled video borescope.
​
-
Camera size: 40mm ⌀ can rotate : 360 °rotating x 180° with focus: Manual Adjustable Sensor: 1/4" colour CMOS Lens : f=3.6, F=2.3 View Angle: 90° Light: 12 LED lights Waterproof: IP67
-
Camera size: 24mm ⌀ Forward Viewing having a field of view of 100dg
-
Camera size 8mm ⌀ Video Borescope with Two-way steering
-
Length options: 1.5m-3m FOV: 10-1 00mm/25-oo Bending angle: two way, >120°
-
Display Screen 7″ Touch LCD (800*480)
-
Semi-Rigid Fiberglass Pushrod Cable Material: Fibre cable Diameter: 5.5mm diameter Length: 30m
-
Power Source Removable Battery Capacity: 11.1V, 7000MAH
-
Removable Battery with LED power indicator Working Time: More than 4 hours
-
The system is designed to record Video/ Photo capture for playback on-site or share with your client
-
Date & Time stamping of recorded jobs
-
Video 640*480 ASF
-
Kits Working temperature: -10°C-50°C Language: 14 languages
-
Memory: 64G (standard)
The Dellon PTZ41 Push Rod
Inspection System
The Dellon PTZ41 Features
​​
The PTZ41 multi-function all-in-one pipe camera which adopts advanced tech and equipment features with a high-definition rotating camera can be used to inspect the pipe from 10mm to 300mm. The PTZ41 is convenient, flexible, and economic, this system meets plenty of our customers' needs for varying inspections of regions of interest
​
-
Camera size: 40mm ⌀ can rotate : 360 °rotating x 180° with focus: Manual Adjustable Sensor: 1/4" colour CMOS Lens : f=3.6, F=2.3 View Angle: 90° Light: 12 LED lights Waterproof: IP67
-
Camera size: 24mm ⌀ Forward Viewing having a field of view of 100dg
-
Camera size 8mm ⌀ Video Borescope with 4-way steering
-
Length options: 1.5m-3m FOV: 10-1 00mm/25-oo Bending angle: two way, >120°
-
Display Screen 7″ LCD (800*480)
-
Semi-Rigid Fiberglass Pushrod Cable Material: Fibre cable Diameter: 5.5mm diameter Length: 30m
-
Power Source Removable Battery Capacity: 11.1V, 7000MAH
-
Removable Battery with LED power indicator Working Time: More than 4 hours
-
The system is designed to record Video/ Photo capture for playback on-site or share with your client
-
Date & Time stamping of recorded jobs
-
Video 640*480 ASF
-
Kits Working temperature: -10°C-50°C Language: 14 languages
-
Memory: 64G (standard)
The Dellon 8.4mm Pushrod Camera System
The Dellon 8.4mm Pushrod Kit
​​
Available from EN DE TEK for Purchase or Rent is our Mini Push Probe Kit which comprises an interchangeable forward-viewing 8.4mm ø camera head, offering a 25mm to ∞ focussing range that operates together with its 30 Mtr Pushrod that's housed inside a stainless steel reel and complete with a 7" intelligent touchscreen display controller that is all housed inside a rugged trolley style transport case.
Once you own the 7" intelligent touchscreen display you can expand further to incorporate varying inspections because more accessories are capable of being integrated by purchasing an upgraded reel to use more interchangeable camera heads such as a 40mm Pan/Tilt Camera, 24mm Forward View Camera, Rigid Cameras, Video Borescopes.
​
The Dellon Binocular Measurement Videoscopes
The Dellon SVPro Scanning Measurement Videoscopes
