ETher NDE Eddy Current Solutions

Eddy Current Flaw Detectors

Eddy Current AeroCheck Instruments

AeroCheck



The AeroCheck family currently includes the AeroCheck 2 and the AeroCheck+.

The AeroCheck 2 is the successor to the original AeroCheck, with the addition of software functions: Guides and Loop & Trace.

The AeroCheck+ has all the features of the Areocheck 2 with the addition of Dual Frequency and Conductivity Measurement.

Download
Eddy Current WeldCheck Instruments

WeldCheck 2



The WeldCheck 2 EC Flaw Detector is a lightweight, compact instrument built in a tough aluminium casing.

WeldCheck+ improves on the WeldCheck 2 as it adds dual-frequency capability, Automatic Lift Off Gain Compensation and Conductivity Measurement. Dual-frequency allows coating thickness measurement alongside defect detection.

Download
WeldCheck 3
WeldCheck 3 dual-frequency eddy current flaw detector
Download

The WeldCheck 3 is a dual-frequency eddy current flaw detector, with conductivity, which means that the instrument can be used for dual and single frequency applications.

With improved physical and ergonomic design the WeldCheck 3 brings ETher NDE’s WeldCheck series right up-to-date.  Based on in-field operator feedback and embracing the use of new case materials, the WeldCheck 3 delivers the end user enhanced ruggedness, a toughened screen, improved connector access and performance, combined optional features such as an encoder wheel.

The WeldCheck 3  is ideal and adaptable across an extremely wide variety of eddy current inspection tasks due to its superior performance;  including weld inspection, surface defect detection and low frequency inspection of non-ferrous material. Equipped for all environments The WeldCheck 3 has been built come up against some of the harshest working conditions in the NDT industry, including the rope access environment being lifted and lowered on ropes, knocked and dropped. With a rear foot stand and four harness attachment points, the WeldCheck 3 is adaptable to be used in various environments from the desktop, in the office, to the rigours of the job site.  New over-moulded rubberised corners deliver enhanced impact protection and improved overall ruggedness. Internally the design is optimised to resist moist, tropical or salt-laden atmospheres, designed to meet IP64, performing reliably across inhospitable environments. Toughened daylight visible, large colour screen

Being able to see the instrument screen clearly throughout all types of weather and light conditions is a top priority.  The WeldCheck 3 has a fully daylight readable 14.5cm LCD Colour Screen of 640 x 480 pixels ensuring the operator has crisp presentation no matter what the working conditions are. The screen is further enhanced with a 2mm thick anti-reflective polycarbonate protector sheet which has excellent impact strength and added UV protection thanks to an anti-glare coating.  The operator has the choice of configuring their own colour schemes and display types, further optimising viewing ability according to environmental conditions.

Extraordinary battery life With more than 7 hours battery life, running with a 100kHz Weld Probe and maximum back-lighting, the WeldCheck 3 is an obvious choice when faced with a long day of Eddy Current NDT.





WeldCheck 3 dual-frequency eddy current flaw detector
WeldCheck 3 dual-frequency eddy current flaw detector
WeldCheck 3 dual-frequency eddy current flaw detector
WeldCheck 3 dual-frequency eddy current flaw detector
WeldCheck 3 dual-frequency eddy current flaw detector
PhaseCheck, an advanced dual probe, dual frequency advanced eddy current flaw detector with C-Scan

PhaseCheck



Introducing the latest addition to our core range, the PhaseCheck, an advanced dual probe, dual frequency advanced eddy current flaw detector with C-Scan capability.

For the first time in the field of portable NDT instruments the PhaseCheck delivers the operator with a hand-held high-end eddy current flaw detector package, delivering C-Scan data display.  As the saying goes “a picture is worth a 1000 words” and to date “pictures” , such as the inspection data displayed in C-Scan images,  have been limited to expensive large laboratory instruments.

Download
ETHER NDE

Conductivity Meters

Sigmacheck Eddy Current (ECT) Conductivity Meter
Sigmacheck Eddy Current (ECT) Conductivity Meter in use
Sigmacheck Eddy Current

SigmaCheck 2



The SigmaCheck2 Eddy Current (ECT) Conductivity Meter is designed to provide the user with fast and accurate conductivity measurements at a reasonable price.

The SigmaCheck2 EC Conductivity Meter is extremely easy to use making it suitable for use by shop inspectors or engineers.

The SigmaCheck2 ET Conductivity meets the requirements for conductivity measurements in the Aircraft manufacture and maintenance fields where conductivity measurements are used to verify proper alloy/temper or detect heat damaged components. The SigmaCheck2 Eddy Current Conductivity Meter is also useful to determine the purity of precious metals (counterfeit detection) such as gold bullion and coins.

Download
ETherNDE Eddy Current Sets
PhaseCheck Complete

Eddy Current Probes

Eddy Current Probes Custom and Cross Compatible

ETher NDE can offer a full range of Standard Probes, Weld Probes, Special Probe Design services and a wide choice of Probe Accessories. With Probe manufacturing based in-house, ETher have the ability to guarantee you the quality you expect from you Eddy Current Probes.

Magnetic Flux Leakage.

Eddy Current Tube Inspection Systems

SteelCheck

SteelCheck is a battery operated 3 channel (Hall Sensor and 2 coil) tube inspection unit for Carbon Steel (Ferromagnetic Tubes) using Magnetic Flux Leakage. Unlike other remote field eddy current method it is unaffected by external Aluminium Fins and has the capability to discriminate between external and internal defects. Packaged as a highly portable, battery operated flaw detector at an attractive price, the SteelCheck offers exceptional value for money.

Download
Download

Eddy Current Instruments

Eddy Current Tube Testing Systems

The ETi-300 and Ether’s suite of software solutions deliver an advanced end-to-end solution for tube inspectors. Realizing that the inspection process is more than just recording data the ETi-300 was conceived to work with a software suite of solutions, improving on-site workflow and delivering rapid and accurate reporting.

ETi-300 Eddy Current Flaw Detector

The ETi-300 is an advanced eddy current tube testing instrument for inspecting non-ferrous tubing from the inner diameter (ID), developed by ETher NDE to perform in the most demanding of environments whilst delivering outstanding inspection results and reporting functionality. Eddy Current testing has long been acknowledged as the fastest, most efficient, and most effective inspection method to inspect the large quantity of non-ferrous tubes present in a typical heat exchanger. The ETi-300 instrument and its suite of analysis and reporting software are ideal for heat exchanger and condenser inspection applications within Power Generation, Transportation, Petrochemical Oil, and Gas industries.

Download
Eddy Current Tube Testing Systems
Eddy Current Tube Testing Systems
Eddy Current Push Probes

As part of the Tube Inspection suite of solutions we offer:



  • TMR Mapping allows tube map templates to be created to enable inspection planning using either photographs, drawings, or rapid manual entry

  • ETherMap is the Data Analysis software for the ETi-300

  • TMR Reporting processes the analyzed data and turns it into a meaningful and informative report.

ETherMap

Data Analysis & User interface

ETherMap is not only the data analysis tool but also the main user interface to the head-less (no screen) instrument. This versatile software was developed to be directly connected to our latest instruments where it can control and receive live inspection data in the field, or work with previously recorded data. EtherMap is an intuitive user interface for the ETi 300 operator, capable of processing and analyzing data on its own or as an integral part of our end-to-end offering with TMR. When integrated with TMR the user can go all the way from Tube Map design, inspection, and analysis to report generation.

Inspection planning with TMR ET*



Advanced Tub Mapping Software

In order to offer the best user experience when it comes to tube map design and report generation, Ether NDE has teamed up with Talcyon Pte Ltd, to deliver advanced Tube Mapping Software (TMR) which is second to none in its features and ease of use. Tube Mapping Software (TMR) is a solution intuitively designed with the operator and tube inspection task in mind; specifically to produce an accurate layout and labelling of tubes on a tube sheet. Upload a photograph or schematic diagram of the tube sheet and create a map of the tube sheet, assigning a number to each of the tube openings. The “tube sheet” presents the software with a graphic representation, which helps to track which tubes have already been measured, aiding efficient workflow, labelled, and mapped.

Probes

ID Bobbin Probes



Ether NDE design and manufacture a wide range of ID (Internal Diameter) Differential Bobbin probes:



  • Probe diameters from 7.5 to 150mm, available in 0.1mm steps

  • Dis-connectable and integral probe cables

  • Cable lengths from 3 to 30 meters

  • Frequency range from 2.7 kHz to 1MHz, centre frequencies 2.7, 10, 24, 76, 190, 400kHz



Report Creation with TMR ET*

Automated Report Creation

A fast reporting software designed to manage data gathered from inspections, with the capability to present inspection data in easy-to-read formats. Reports are generated using the simple user interface, whilst fully-customizable reporting and output are easily configurable. Report templates are viable to save time and can be built and populated by simply placing elements using a “drag and drop” method. Bespoke and unique reports can be delivered using the report-building software features to customize your reports.

Eddy Current Tube Testing ECT Software
EC Analysis Software
Advanced Tub Mapping Software

Veescan Automated Wheel Inspection Systems

Aircraft Wheel Inspection Systems Veescan

The VEESCAN is ETher's first Wheel Inspection System and offers maximum flexibility. The VEESCAN has a proven mechanical design and established record of breakdown-free operation for 365 days or more. Appealing to many companies in the Aerospace industry, the VEESCAN is ideal in all aircraft wheel-testing environments.


The VEESCAN is able to be configured with a wide choice of probes and allows any wheel testing facility the flexibility to select the system most compatible with their workload. Teamed with a full choice of operation modes, the VEESCAN maximizes the probability of detection.
The VEESCAN is offered with the ETher NDE guarantee of complete client satisfaction and excellent technical support.

Download
Wheel Inspection Systems Veescan
Veescan Eddy Current Wheel Flaw Testing Systems

Maxwell NDT Pulsed Eddy Current Technology

Maxwell PECT



ETher NDE represent globally the Maxwell NDT pulsed eddy current technology (PECT) product.

With unbeatable inspection capability and a truly simple user interface, we challenge you to test the Maxwell system side by side against any other PEC system and prepare to be surprised!

A no nonsense, capable and flexible PEC inspection tool which has been developed for harsh industrial environment inspections as well as applications in splash zones, subsea inspections and ROV deployments.

Pulsed Eddy Current Systems

Pulsed Eddy Current (PEC) is an inspection technique for inspecting carbon steel objects such as pipes and vessels, without the need for contact with the steel surface. PEC can measure percentage variations in steel thickness through any non-conductive and non magnetic materials between sensor and surface such as air, insulation material, concrete, plastics, coatings, sea water and marine growth, paint, deposits, oil, composite repairs, fireproofing, “scabs” aluminium sheeting and other non-magnetic insulation covers; so ideal for Corrosion Under Insulation (CUI) applications. Previous instruments often lacked the power to be fast and effective.

Using the latest battery technology, MAXWELL NDT introduces a novel and very powerful PECT instrument with a design based on 25 years’ hands-on experience at a global Oil Company.

Pulsed Eddy Current System Australia
Pulsed Eddy Current Systems

Pulsed Eddy Current (PECT) is an inspection technique for inspecting carbon steel objects such as pipes and vessels, without the need for contact with the steel surface. PECT can measure percentage variations in steel thickness through any non-conductive and non magnetic materials between sensor and surface such as air, insulation material, concrete, plastics, coatings, sea water and marine growth, paint, deposits, oil, composite repairs, fireproofing, “scabs”, aluminium sheeting and other non-magnetic insulation covers; so ideal for Corrosion Under Insulation (CUI) applications

The MAXWELL PECT instrument is designed for the inspection of carbon steel and low-alloyed steels, which are magnetic. For magnetic test specimens, the eddy currents are concentrated on the surface directly after the magnetic pulse. Subsequently, the eddy currents diffuse into the test specimen, until the backwall is “reached”. This results in a characteristic shape A-scan: a straight line, corresponding to the diffusion of the eddy currents, followed by curved section when the backwall is sensed.

  • PECT can normally be applied to ferromagnetic steel with wall thickness (WT) between 2.5mm - 65mm (0.1” - 2.5”). Th lift-off range is 0-250mm ( 0-10”).

  • Weighing in at 7.2kg (16lbs), including the batteries, the MAXWELL system is highly portable; and with a typical battery life of 8 hours is an ideal inspection partner in the field.



  • A maximum surface temperature of up to 550°C (1020°F) may be inspected with the PECT technique, provided the PECT probe is kept below 70°C (160°F).

Advanced Eddy Current with Maxwell Pulsed Eddy Current
Underwater PECT Probe Set
Advanced Eddy Current with Maxwell Pulsed Eddy Current
Detect flaws and corrosion in ferrous materials typically hidden under layers of coating, fireproofing, or insulation.
PECT Lift-Off range of probes
Pulsed Eddy Current Batteries
